VISUAL 344

Modular housing post for access control system

ACCESS CONTROL EQUIPMENT

Utility post in support of installations where road barriers or automatic, retractable bollards are used as it provides room inside it for the command and safety accessories.

VERSATILE

It consists of stackable modules, either having a lockable door and the inside is accessed by a coded key, or having one or two aluminium front panels to fit various command and safety accessories into them, as well as two- or threehead LED traffic lights. It is made of cataphoresis treated and powder coated S235JRH steel well withstanding the atmospheric agents.

Cylinder diameter (mm)

Cylinder thickness (mm)

Cylinder length (mm)

Cylinder height from ground (mm)

Cylinder material

Treatment and finishing

Impact resistance (J)

Breakout resistance (J)

Weight (kg)

100

1.000

500/600/800

acciaio S235JRH

cataphoresis and polyester powder coating RAL 7016

30.000

150.000

Fixed bollard for traffic control. The recommended height from ground level to match the automatic ones, can be 500, 600 or 800 mm. S235JRH steel cylinder, 5 mm thickness and ø 100 mm, cataphoresis treated and polyester powder coated. Cylinder head made of aluminium with rubber edge. Cylinder with an approved, retro-reflecting, high intensity, micro-prismatic adhesive film (h 80 mm), designed to take 4 amber colour signalling LED lights, radially fitted. Breakout resistance 150.000 J. Ideal for installations in private, commercial areas and city centres.
